Plinky 8-Voice Polyphonic Touch Synthesiser (24HP) Eurorack & Desktop Synth Black

Description

Plinky is an 8 voice expressive polyphonic touch synthesizer that specializes in fragile, melancholic sounds, designed by mmalex.

Think of it as an eight stringed instrument, with eight vertical monophonic strips. You can play it straight away on its 64 main pads. Each of the eight strings has 4 oscillators or sampler grains, detuned by the touch of your fingers, white noise, two ADSR envelopes and a resonant 2-pole low-pass gate. Plinky also has a global delay, reverb, high pass filter and saturation along with a simple mixer, arpeggiator, sequencer and sampler. It supports four external CV modulation sources, each with their own LFO.

Plinky v3 integrates TRS MIDI input and output directly on-board, so you sequence polyphonic chords externally and play a melodic line on top on its touch surface.

Input:
4 x CV
Audio In (Front, Back, Panel)
Clock
Pitch
Gate
Midi In (TRS)
USB (Front, Back)

Output:
Mono L/R (Panel)
Phones (Front, Back)
Clock
Trigger
Pitch (High/Low)
Gate
Pressure
Midi Out (TRS)

This is the Desktop version of this unit, but it can also used as an Eurorack module.

delivery includes:
– ribbon cable
– USB A – USB C Cable (1m)
– screws incl. protection washers
– Self-adhesive rubber feet

conditions
– Brandnew Build (built under professional conditions)
– Tested
– Calibrated

OPEN SOURCE HARDWARE

The plinky logo and the design of the front panel design and all other graphic elements (both in code and in the documentation and hardware design) are CC BY-SA 4.0
