uRings /// Mutable Instruments Eurorack Module /// Rings Clone /// Black/White
175,00 €
8HP Mutable Instruments Rings Clone for Eurorack
No VAT statement, as small business owner according to §19 (1) UStG. plus shipping costs
Description
nRings is a micro version of the physical modelling beast, Rings from Mutable Instruments for your Eurorack.
A digital, voltage-controllable resonator that is ideal for creating physical modelling sounds. It offers three different resonator modes and a four-voice pseudo-polyphony. Two outputs provide different overtone structures or different notes in polyphonic mode.
nRings simulates three different types of vibrating structures:
- Strings
- Membranes
- Tubes
There are two outputs, ODD and EVEN. In monophonic mode, complementary signals are output at these. In the polyphonic modes, the first and third vibrating bodies are output to ODD, the second and fourth to EVEN.
The “Live V1” firmware is installed on the module.
This is just a very minor change from the official firmware, making it easier to enter/exit the “disastrous peace” easter egg. You can now enter easter egg mode by doing a long press of the “mode” button when already in an alternate mode.
So, for example, from the initial “modal resonator” (solid green LED) mode, to get to easter egg mode:
long press “mode” button for 5 seconds. Green LED is now slowly pulsing, you are now in FM Voice mode.
long press “mode” button again for 5 seconds. Both LEDs will flash red/green. You are now in easter egg mode.
long press “mode” button again for 5 seconds. You are back in “modal resonator”.
While in easter egg mode, a short press of “mode” changes the FX applied to the string synth.
While in an alternate mode (pulsing mode LED), a short press of “mode” returns to the original 3 modes.
While in an original mode, a short press of “mode” iterates through the three original modes.
Additional information
| TE | 8 |
|---|---|
| +12V | 120 mA |
| Licenc | OPEN SOURCE HARDWARE PCB & Schaltplan von Jakplugg unter Creative Commons CC-BY-SA-3.0 Lizenz. Original CAD-Datei, PCB & Schaltplan und originale Designelemente von Mutable Instruments (Émilie Gillet) unter Creative Commons CC-BY-SA-3.0 Lizenz |
